Product Overview: 74AUP2G132GN,115

The 74AUP2G132GN,115 is a high-performance, dual-input NAND gate integrated circuit (IC) produced by NXP Semiconductors. This advanced ultra-low-power component is part of the AUP (Advanced Ultra-low Power) family, designed to operate with a very low power consumption, making it ideal for use in power-sensitive applications.

The device is housed in a compact, leadless XSON8 package with a body size of 1.35 x 1.0 mm, which is suitable for space-constrained applications. The small form factor, coupled with the low power characteristics of the 74AUP2G132GN,115, makes it a perfect choice for portable and battery-operated devices where efficiency is crucial.

Key Features:

• Low Power Consumption: The IC is engineered to operate with a very low power supply, ranging from 0.8V to 3.6V, which helps in extending battery life in portable devices.
• High-Speed Operation: Despite its low power design, the 74AUP2G132GN,115 does not compromise on speed, offering high-speed operation with a typical tpd of 3.7 ns at 3.3 V.
• Advanced Design: The device features Schmitt-trigger action at all inputs, which makes the circuit tolerant to slower input rise and fall times, and is capable of translating low amplitude signals into clean output signals.
• Wide Operating Temperature: The IC can operate over a broad temperature range from -40°C to +125°C, ensuring reliable performance under varying environmental conditions.
• ESD Protection: It includes input and output protection against electrostatic discharge (ESD), enhancing the robustness of the device in handling and operation.
• Compliance: The product is compliant with JEDEC standard no. 8-1A and is RoHS compliant.

Applications:

The 74AUP2G132GN,115 is versatile and can be used in a variety of applications, including but not limited to:

• Smartphones and tablets
• Portable media players
• Wearable technology
• IoT devices
• Medical devices
• Low-power instrumentation

In summary, the 74AUP2G132GN,115 from NXP Semiconductors offers designers a balance of power efficiency and performance, packaged in a small footprint, making it an excellent choice for modern electronic applications where space and power are at a premium.
