Product Overview: 74HC595D,118

The 74HC595D,118 is a high-speed Si-gate CMOS device and is part of the 74HC/HCT family. Manufactured by NXP Semiconductors, this integrated circuit is designed for applications that require the capture of data at high speeds and the subsequent serial-to-parallel conversion of this data. The chip is particularly useful in systems where there is a need to significantly expand the number of output lines through serial data input, which can help to save on microcontroller pins and simplify design.

Key Features

• Shift Register: The device contains an 8-bit serial-in, parallel-out shift register that feeds an 8-bit D-type storage register.
• Output Drive Capability: It can drive up to 15 LSTTL loads and has a high current source/sink for direct drive of LEDs.
• Operating Voltage: The 74HC595D,118 operates at a wide range of voltages from 2.0V to 6.0V, making it compatible with many logic families and power requirements.
• Shift Register Clock: A separate clock input is provided for the shift register, which also features a clear function.
• Storage Register: The storage register has a parallel 3-state output enabling direct connection to the bus lines.
• Frequency: It has a high maximum clock frequency of 100 MHz, ensuring suitability for high-speed applications.

Applications

The 74HC595D,118 is versatile and can be used in a wide array of applications such as:

• Serial-to-parallel data conversion
• Remote control holding registers
• LED displays and LED signboards
• Logic system extension and bus expansion
• Automotive, medical, and consumer electronics

Package and Quality

The device is offered in an SO16 package, which is a small-outline package with 16 leads. This makes it compact and suitable for space-constrained applications. NXP's commitment to quality ensures that the 74HC595D,118 meets the stringent requirements of the industry, providing reliable performance in a range of environmental conditions.

With its robust design, flexible usage, and NXP's reputation for reliability, the 74HC595D,118 is an excellent choice for designers looking to implement efficient serial-to-parallel data conversion in their digital logic circuits.
