Products specifications

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 320mA
Maximum Rds On at Id,Vgs 1.6 Ohm @ 300mA, 10V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 0.8nC @ 4.5V
Max Input Capacitance 50pF @ 10V
Maximum Power Dissipation 420mW
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-TSSOP
Win Source Part Number 237375-BSS138P
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Audio, Signal Processing, Power Management, Communications & Networking, Industrial
Family Name BSS138P
Introduction Date July 12, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian BSS138P CAD Model

Description

The BSS138P is a high-performance, N-channel Logic Level Enhancement Mode Field Effect Transistor (MOSFET) produced by NXP Semiconductors. This particular component is designed to offer efficient power control and switching in a wide range of applications. With its compact size and low on-resistance, the BSS138P is a preferred choice for designers looking to optimize power consumption and thermal performance in their circuits.

Key Features

  • Low On-Resistance: The BSS138P boasts an extremely low on-resistance, typically at 3.5Ω, which ensures minimal power loss and heat generation during operation.
  • High-Speed Switching: This MOSFET is capable of fast switching speeds, making it suitable for high-frequency applications.
  • Logic Level Compatibility: It can be directly driven by logic level voltages (1.8V to 5V), eliminating the need for level shifters in most cases.
  • Low Threshold Voltage: The low threshold voltage allows for easy control of the transistor at lower gate voltages, providing greater flexibility in circuit design.
  • SOT-23 Package: The compact SOT-23 package is ideal for space-constrained applications and helps in reducing the overall footprint of the circuit design.

Applications

The BSS138P is suitable for a variety of applications, including:

  • Load/Power Switching
  • DC-DC Converters
  • Power Management Functions
  • Motor Control Circuits
  • Line Drivers
  • Level Shifting Applications

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and reliability, and the BSS138P is no exception. It is manufactured to meet the high standards expected from NXP products, ensuring stable performance and longevity in the field.

Environmental Considerations

The BSS138P is RoHS compliant and free from environmentally harmful substances. NXP is dedicated to producing environmentally sustainable components that meet current regulations and standards.

Overall, the BSS138P from NXP is a versatile and reliable component that provides efficient power control in a variety of electronic applications. Its low on-resistance, logic level compatibility, and fast switching capabilities make it an excellent choice for modern, energy-conscious designs.
