Products specifications

Category Sensors, Transducers - Temperature Sensors - Analog and Digital Output
Mfr NXP
Series UMW DS18B20
Package Bulk
Product Status Active
Sensor Type Digital, Local
Sensing Temperature - Local -55°C ~ 125°C
Output Type 1-Wire®
Voltage - Supply 2.5V ~ 5.5V
Resolution 9 b, 10 b, 11 b, 12 b
Features Standby Mode
Accuracy - Highest (Lowest) ±0.4°C
Test Condition -10°C ~ 70°C
Temperature Range - Operating -55°C ~ 125°C
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package TO-92
Standard Package 2,000 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 112152-DS18B20
Ultra Librarian 3D Model Ultra Librarian DS18B20 CAD Model

Description

Introducing the DS18B20 Digital Temperature Sensor from NXP

The DS18B20 is a versatile and reliable digital temperature sensor from NXP Semiconductors, designed for easy integration into a wide range of applications. This sensor offers high-precision temperature measurements with a digital output, making it an ideal choice for environmental monitoring, HVAC systems, and industrial control processes.

Key Features

  • High Accuracy: The DS18B20 provides ±0.5°C accuracy from -10°C to +85°C, ensuring precise temperature readings for critical applications.
  • Wide Temperature Range: Capable of measuring temperatures from -55°C to +125°C, this sensor is suitable for extreme environmental conditions.
  • Programmable Resolution: Users can configure the resolution of the DS18B20 from 9 to 12 bits, allowing flexibility between resolution and conversion time.
  • One-Wire Interface: The sensor uses NXP's proprietary one-wire bus, which simplifies system design by requiring only one data line (and ground) for communication with a central microprocessor.
  • Multiple Sensors on One Bus: It is possible to operate several DS18B20 sensors on the same one-wire bus, making it easy to implement multi-point temperature sensing networks.
  • Power Supply Range: The sensor can be powered from a 3.0V to 5.5V supply, or it can derive power directly from the data line ("parasite power"), minimizing the need for an external power supply.

Applications

  • Environmental Monitoring Systems
  • Building Automation and HVAC Systems
  • Industrial Temperature Control
  • Thermostatic Controls
  • Consumer Electronics

With its robust design and easy-to-use one-wire interface, the DS18B20 from NXP is a top choice for professionals and hobbyists alike. Its ability to provide accurate and consistent temperature readings in a compact package makes it a go-to sensor for a variety of temperature monitoring solutions.

Whether you're developing a sophisticated climate control system or simply need to monitor temperatures within your DIY project, the DS18B20 offers the performance, reliability, and convenience you need to get the job done right.
