Products specifications

Manufacturer NXP
Win Source Part Number 1178033-GTL2002DC
Manufacturer Homepage www.nxp.com
Family Name GTL2002
Introduction Date April 01, 2003
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian GTL2002DC CAD Model

Description

The NXP GTL2002DC is a versatile and high-performance dual bidirectional voltage-level translator designed for bidirectional voltage translation between two logic levels. This device is part of NXP's advanced level-shifting product family and is specifically tailored to address the needs of multi-voltage systems where signal integrity and flexibility are paramount.

Key Features

  • Wide Voltage Range: The GTL2002DC operates over a broad voltage range of 1.0V to 3.6V on the A port and 1.8V to 5.5V on the B port, making it suitable for translating between low-voltage and higher-voltage logic levels.
  • Bidirectional Translation: This device allows for seamless communication in both directions without the need for direction control, simplifying the design and reducing the overall component count.
  • High-Speed Operation: With its capability to support high-speed signal transfer, the GTL2002DC is ideal for applications requiring fast data rates, ensuring minimal signal delay and high-integrity signal translation.
  • Flow-Through Design: The pinout of the GTL2002DC is designed for easy PCB layout, with a flow-through design that simplifies the routing of traces between the input and output.
  • Low Standby Current: The device features a low standby current, which is beneficial for power-sensitive applications.

Applications

The NXP GTL2002DC is particularly useful for interfacing devices operating at different voltage levels within a system. Its applications span across various fields such as:

  • Mobile Phones
  • Personal Digital Assistants (PDAs)
  • Laptops and Desktop Computers
  • Embedded Systems
  • Signal Bridging between different logic levels

Package and Quality

The GTL2002DC comes in a compact leadless package (XSON8), which is designed for space-constrained applications. NXP's commitment to quality ensures that the GTL2002DC meets stringent industry standards for reliability and performance, making it a trustworthy choice for designers looking to bridge voltage levels in their digital systems.

Overall, the NXP GTL2002DC stands out as a robust and efficient solution for voltage level translation, offering design flexibility, high-speed performance, and compatibility with various logic levels to meet the requirements of modern electronic systems.
