Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor ARM7
Part Core Size 16/32-Bit
Speed(Frequency) 70MHz
Number of I/O 32
Program Memory Size 32KB (32K x 8)
Program Memory Type FLASH
Data RAM Size 8K x 8
Supply Voltage - Operating 1.65 V to 3.6 V
Data Converters A/D 8x10b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 48-LQFP (7x7)
Win Source Part Number 088940-LPC2103FBD48
Family Name LPC2103
Introduction Date December 27, 2005
ECCN 3A991.a.2
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LPC2103FBD48 CAD Model

Description

The NXP LPC2103FBD48 is a highly integrated microcontroller designed for embedded applications that require low power consumption, high performance, and minimal footprint. It is part of the LPC2100 family based on a 32-bit ARM7TDMI-S CPU that operates at frequencies of up to 70 MHz. This microcontroller is an ideal choice for industrial control, medical systems, automotive electronics, and other applications where efficient processing and reliability are paramount.

Key Features:

  • Core: ARM7TDMI-S processor running at up to 70 MHz.
  • Memory: 32 KB of on-chip static RAM and 128 KB of on-chip flash memory.
  • Digital Peripherals: Includes multiple 32-bit timers, an efficient vectored interrupt controller, and up to 47 GPIO pins.
  • Communication Interfaces: Features serial interfaces such as UART, I2C, SPI, and SSP for easy data transfer and communication with peripherals.
  • Package: Available in a compact 48-pin LQFP package, allowing for space-saving PCB designs.
  • Power Management: Comes with an integrated power management unit that supports multiple power-saving modes to reduce energy consumption.
  • Debugging and Emulation: Supports JTAG and Embedded Trace Macrocell (ETM) for comprehensive debugging capabilities.

Applications:

The LPC2103FBD48's versatile feature set makes it suitable for a wide array of applications. Some common use cases include:

  • Industrial automation and control systems
  • Medical devices and healthcare technology
  • Automotive electronics and infotainment
  • Utility meters and environmental monitoring systems
  • Consumer electronics

Why Choose LPC2103FBD48?

With its robust architecture, comprehensive feature set, and power efficiency, the NXP LPC2103FBD48 is a reliable microcontroller that offers designers a great balance of performance and cost. Its extensive support for communication protocols and real-time processing capabilities ensures that it can meet the demands of sophisticated and varied applications. Moreover, the availability of development tools and software libraries facilitates a smooth design experience and rapid deployment of systems based on the LPC2103FBD48.
