Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer NXP
Packaging Tray
Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 6
Voltage Supply MIN 5V
Voltage Supply MAX 21V
Voltage - Output 8 V ~ 60 V
Output Current per Channel 2.3A (Switch)
Frequency 600kHz
Dimming PWM
Applications Backlight
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 24-UFQFN Exposed Pad
Manufacturer Package 24-QFN-EP (4x4)
Win Source Part Number 787782-MC34845CEP
Popularity Medium
Supply and Demand Status Balance
Family Name 34845
Introduction Date March 05, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian MC34845CEP CAD Model

Description

The NXP MC34845CEP is a highly integrated, advanced LED backlight driver designed to cater to the growing demands of high-resolution display technologies. This sophisticated device is engineered to provide precision control for LED backlights in medium to large-sized LCD panels, making it an ideal solution for applications such as TVs, desktop monitors, and industrial displays.

Key Features

  • Multiple Output Channels: The MC34845CEP comes equipped with multiple output channels that can drive up to 160 LEDs in series, offering flexibility and scalability for various display sizes and configurations.
  • High Efficiency: With an integrated boost converter, the device ensures high efficiency and low power consumption, which is crucial for energy-saving in consumer electronics.
  • Precision Dimming Control: The device supports both analog and pulse-width modulation (PWM) dimming methods, allowing for precise brightness control and enhancing the viewer's visual experience.
  • Fault Protection: It includes comprehensive fault protection features such as LED open/short detection, overvoltage, overcurrent, and thermal shutdown, ensuring reliable operation and extending the lifespan of the backlight system.
  • I²C Interface: An I²C-compatible interface is provided for easy communication and programming of the driver settings, enabling a high level of customization and control.

Applications

  • LCD TV Backlighting
  • Desktop Monitor Backlighting
  • Industrial Display Systems

Technical Specifications

  • Input Voltage Range: 4.5V to 40V
  • LED Output Voltage: Up to 60V
  • Communication Interface: I²C-compatible
  • Operating Temperature Range: -40°C to +85°C
  • Package: 24-pin QFN

The NXP MC34845CEP is not merely a component; it's a robust solution designed to enhance the performance and efficiency of LED backlighting systems. Its integration of multiple features into a compact form factor makes it a smart choice for manufacturers looking to deliver high-quality display products to the market.
