Product Overview: MC9S08GT16ACFBE

The MC9S08GT16ACFBE is a versatile microcontroller unit (MCU) from NXP's S08 family, designed to deliver exceptional performance and reliability for a wide range of embedded applications. This 8-bit MCU is built on NXP's high-density, cost-effective HCS08 core, which operates at a maximum frequency of 40 MHz. The device is housed in a 44-QFP (Quad Flat Package) and is known for its low-power consumption, making it an ideal choice for battery-powered and portable devices.

With 16KB of on-chip flash memory, the MC9S08GT16ACFBE provides ample space for application code and data storage, ensuring smooth and efficient operation. The flash memory is accompanied by 1KB of RAM, allowing for quick data processing and temporary data storage during runtime.

This MCU features a rich set of peripherals, including an 8-channel, 10-bit Analog-to-Digital Converter (ADC) that allows for precise measurement of analog signals, making it perfect for sensor interfacing and data acquisition tasks. The device also includes multiple communication interfaces such as an I2C bus, a Serial Peripheral Interface (SPI), and a Serial Communication Interface (SCI), offering excellent connectivity options for various peripherals and other microcontrollers.

The MC9S08GT16ACFBE is equipped with an array of timers, including an 8-channel Timer/Pulse Width Modulator (TPM) module, which is extremely useful for tasks that require precise timing and PWM control, such as motor control applications. The MCU also features a Real-Time Interrupt (RTI) and a Watchdog Timer (WDT) to ensure system reliability and to prevent failure due to software anomalies.

For enhanced security and maintenance, this MCU incorporates a background debug mode that provides non-intrusive debugging capabilities during development, along with the ability to update firmware in the field. The device operates within an industrial temperature range of -40°C to +85°C, ensuring stable performance even in harsh environments.

Overall, the MC9S08GT16ACFBE from NXP is a powerful and reliable microcontroller that offers an optimal balance of processing power, memory, and peripherals, making it a top choice for engineers and developers in the automotive, industrial, and consumer electronics sectors.
