The NXP MC9S08QB8CGK is a high-performance microcontroller unit (MCU) that belongs to the S08 family of 8-bit MCUs. This device is designed to deliver exceptional functionality and versatility, making it an ideal choice for a wide range of embedded applications. The MC9S08QB8CGK is engineered to provide a cost-effective solution without compromising on quality or performance.

Key Features

• Core: 8-bit S08 central processing unit (CPU) with speeds of up to 20 MHz, providing quick and efficient data processing capabilities.
• Memory: Features 8KB of on-chip flash memory, allowing for robust program storage, and 512 Bytes of RAM for efficient data handling.
• I/O Pins: Offers 16 versatile input/output (I/O) pins, which support a range of functionalities and are highly configurable to suit various application needs.
• Analog-to-Digital Converter (ADC): Includes a 10-bit ADC with multiple channels, providing precise analog signal measurement and conversion.
• Timers: Comes with an array of timers, including an 8-bit modulo timer and two 16-bit timers, which are essential for tasks requiring precise timing and event counting.
• Communication Interfaces: Equipped with a serial communication interface (SCI) and an inter-integrated circuit (I²C) bus, enabling seamless data exchange with peripherals and other MCUs.
• Operating Voltage: Operates within a range of 1.8V to 3.6V, allowing for flexibility in power-sensitive applications.
• Temperature Range: Designed to operate reliably over an industrial temperature range, ensuring stable performance under varying environmental conditions.
• Packaging: Available in a compact 16-pin QFN package, which is suitable for space-constrained applications.

Applications

The NXP MC9S08QB8CGK MCU is adept at handling complex tasks within industrial control systems, consumer electronics, automotive modules, and smart sensors. Its robust feature set also makes it an excellent choice for developing Internet of Things (IoT) devices, wearables, and portable medical equipment.
