Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - Microprocessors
Mfr NXP
Series MPC83xx
Package Tray
Product Status Obsolete
Core Processor PowerPC e300
Number of Cores/Bus Width 1 Core, 32-Bit
Speed 533MHz
Co-Processors/DSP Security; SEC
RAM Controllers DDR, DDR2
Graphics Acceleration No
Ethernet 10/100/1000Mbps (2)
USB USB 2.0 + PHY (2)
Voltage - I/O 1.8V, 2.5V, 3.3V
Temperature Range - Operating 0°C ~ 105°C (TA)
Security Features Cryptography, Random Number Generator
Mounting Type Surface Mount
Package / Case 672-LBGA
Supplier Device Package 672-LBGA (35x35)
Additional Interfaces DUART, I2C, PCI, SPI
Base Product Number MPC8349
Standard Package 24 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A002A1 FRE
HTSUS 8542.31.0001
Win Source Part Number 643699-MPC8349EVVAJDB
Ultra Librarian 3D Model Ultra Librarian MPC8349EVVAJDB CAD Model

Description

The NXP MPC8349EVVAJDB is a high-performance, power-efficient integrated processor that is part of the PowerQUICC II Pro family. This processor is built upon the e300 core, which is based on Power Architecture technology, making it a suitable solution for a wide range of applications including networking, storage, and industrial control systems.

Key Features

  • Core: The MPC8349EVVAJDB is built around an e300 core that can run up to 667 MHz, providing a robust platform for complex computing tasks.
  • Memory Support: It includes an integrated memory controller that supports DDR and DDR2 SDRAM, allowing for flexible memory configurations and high-speed data access.
  • Connectivity: This processor offers a wealth of connectivity options, including dual Gigabit Ethernet controllers, USB 2.0, PCI, and RapidIO interfaces, making it highly versatile for various communication protocols.
  • Security: With an integrated security engine, the MPC8349EVVAJDB can handle encryption, decryption, and secure hash functions, which are crucial for secure data transactions.
  • Power Efficiency: Designed with power efficiency in mind, this processor includes power management features that help reduce overall power consumption.

Applications

The versatility of the MPC8349EVVAJDB makes it ideal for a broad spectrum of applications. It is particularly well-suited for:

  • Enterprise and home networking equipment such as routers, switches, and gateways
  • Storage systems including SAN, NAS, and RAID controllers
  • Industrial control systems where reliability and real-time performance are critical
  • Embedded computing applications requiring high-speed data processing and connectivity

Technical Specifications

Attribute Details CPU Core e300 Frequency Up to 667 MHz Memory Support DDR, DDR2 SDRAM Networking Interfaces Dual Gigabit Ethernet Peripheral Interfaces USB 2.0, PCI, RapidIO Security Integrated Security Engine Power Management Yes

In conclusion, the NXP MPC8349EVVAJDB processor is a robust, secure, and power-efficient solution that meets the demands of a wide variety of high-performance embedded applications.
