NXP Low Voltage Dual Supply Translator

The NCX2220GU,115 is a high-performance, low-voltage dual supply translating transceiver designed by NXP Semiconductors. It serves as a bidirectional interface between two logic circuits operating at different voltage levels. This versatile component is essential for applications that require the translation of signals between different voltage domains, such as interfacing microcontrollers with peripherals or memory devices.

Key Features

• Voltage Level Translation: Capable of translating signals between two different voltage domains, ranging from 1.2V to 5.5V on the A side and 1.65V to 5.5V on the B side.
• High-Speed Operation: Supports fast data transfer rates, making it suitable for high-speed interfaces.
• Low Power Consumption: Designed for power-sensitive applications, it operates with minimal power dissipation.
• Auto Direction Sensing: The direction of data transmission is automatically determined without the need for a direction control signal.
• ESD Protection: Integrated Electrostatic Discharge (ESD) protection circuits safeguard the device against static damage.
• Compact Package: Available in a small, leadless DHVQFN14 package, it is ideal for space-constrained applications.

Applications

The NCX2220GU,115 is well-suited for a variety of applications that require voltage level translation, including:

• Mobile Devices
• Computing Devices
• Data Communication Systems
• Consumer Electronics

Technical Specifications

Whether you are developing consumer electronics or sophisticated computing systems, the NCX2220GU,115 from NXP is an excellent choice for ensuring seamless communication between devices operating at different voltage levels.
