Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1235926-PCA9517DP
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Communications & Networking
Family Name PCA9517
Introduction Date October 05, 2004
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian PCA9517DP CAD Model

Description

NXP PCA9517DP Level-Translating I²C-Bus Repeater

The NXP PCA9517DP is a robust level-translating I²C-bus repeater designed to provide bidirectional voltage-level translation in multi-voltage systems. This integrated circuit is essential for applications where the I²C-bus must operate in environments with different voltage levels, such as interfacing between low-voltage microcontrollers and higher-voltage peripheral components.

The PCA9517DP is part of NXP's high-performance I²C-bus interface products that are known for their reliability and versatility. It allows for seamless communication between devices operating at different voltage levels, ranging from 0.8V to 5.5V, which makes it incredibly versatile for various applications. This feature is crucial for modern electronics where devices often operate at different power supply levels.

The device incorporates two bidirectional open-drain channels, A-side and B-side, which are used to switch between the different voltage levels. It also features a hot-swap capability that allows I²C-bus and SMBus systems to remain operational while devices are added or removed, enhancing the flexibility of the system design.

The PCA9517DP is equipped with a slew-rate limited output stage to decrease EMI and to provide a more controlled rise time, thus improving signal integrity on the bus. This feature is particularly important in environments with a high density of electronic components or in applications sensitive to electromagnetic interference.

Packaged in a TSSOP-8 (thin shrink small outline package), the NXP PCA9517DP is designed for compactness and minimal footprint on printed circuit boards. This small form factor is highly beneficial for space-constrained applications such as handheld devices, consumer electronics, and embedded systems.

Overall, the NXP PCA9517DP is an indispensable component for system designers looking to facilitate communication between I²C-bus devices operating at different voltages. Its ability to provide level translation while maintaining signal integrity and its hot-swap capability make it an excellent choice for a wide range of applications in the electronics industry.
