Products specifications

Category Integrated Circuits (ICs) - Interface - Specialized
Mfr NXP
Package Bulk
Product Status Active
Applications Translating Switch
Interface I2C, SMBus
Voltage - Supply 2.3V ~ 3.6V, 4.5V ~ 5.5V
Package / Case 20-SOIC (0.295", 7.50mm Width)
Supplier Device Package 20-SO
Mounting Type Surface Mount
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 653316-PCA9544AD
Ultra Librarian 3D Model Ultra Librarian PCA9544AD CAD Model

Description

The PCA9544AD is a highly versatile and innovative product from NXP Semiconductors, designed to enhance the functionality and performance of I2C-bus multiplexing. This integrated circuit (IC) is a 4-channel I2C-bus multiplexer with interrupt logic, enabling users to connect up to four separate I2C devices to a single I2C bus without any address conflicts. This is particularly useful in complex systems where multiple I2C devices with the same address need to be connected to a single I2C bus.

Key Features

  • Four Selectable Channels: The PCA9544AD allows one of four attached I2C-bus devices to be selected and connected to the main I2C bus, simplifying the design of systems with multiple I2C devices.
  • Interrupt Function: An interrupt function is included, which indicates to the master if any of the multiplexed slaves has an interrupt pending, thereby improving system response time and efficiency.
  • Low Standby Current: The device features a low standby current, making it suitable for power-sensitive applications.
  • Wide Operating Voltage: It operates across a wide range of voltages from 2.3V to 5.5V, providing flexibility for various system designs.
  • High Noise Immunity: With built-in noise filter circuits, the PCA9544AD offers high noise immunity, ensuring reliable operation even in electrically noisy environments.

Applications

The PCA9544AD is ideal for a variety of applications where multiple I2C devices are used. These include, but are not limited to:

  • Server motherboard management
  • Industrial control systems
  • Medical equipment
  • Telecommunications infrastructure

Package and Quality

The PCA9544AD comes in a compact SO16 package, which is suitable for space-constrained applications. NXP ensures high-quality standards for its products, and this IC is no exception. It goes through rigorous testing to guarantee performance and reliability for critical applications.

Overall, the PCA9544AD from NXP is a powerful solution for complex I2C-bus systems, offering enhanced flexibility, reliability, and ease of design for engineers and system integrators.
