The NXP PCA9614DP is a robust I²C-bus extender designed to provide reliable communication over long distances. This innovative component is part of NXP's leading-edge interface products, engineered to enhance the capabilities of the standard I²C-bus by enabling it to reach out over meters instead of meters. The PCA9614DP is ideal for applications requiring remote or distributed I²C-bus connectivity, such as industrial control systems, building automation, and sensor networks.

Key Features

• Extended I²C-bus range: Facilitates communication over greater distances than standard I²C interfaces, maintaining signal integrity over longer cables.
• Differential signaling: Utilizes a differential signal to reduce susceptibility to noise, providing more reliable data transmission in electrically noisy environments.
• Hot-swap capability: Allows devices to be added or removed from the I²C-bus without powering down the system, enhancing flexibility and minimizing downtime.
• High noise immunity: With its robust design, the PCA9614DP is capable of withstanding electrostatic discharge and other transient disturbances, ensuring stable operation.
• Low standby current: Optimized for power-sensitive applications, this extender has a minimal standby current, contributing to overall energy efficiency.

Applications

The PCA9614DP is versatile and can be implemented in a variety of settings, including:

• Industrial control systems
• Building automation and HVAC systems
• Sensor networks and remote sensors
• Automotive infotainment and telematics

Package Information

The PCA9614DP comes in a compact TSSOP8 package, which is ideal for space-constrained applications. Its small footprint and low profile make it suitable for integration into a wide range of electronic devices.

Ordering Information

Product is available under the orderable part number PCA9614DP,123. For detailed specifications, sample requests, and ordering information, customers should visit the NXP website or contact their local NXP sales office.
