Same model may have multiple batches, images only for reference.

PCF8562TT/2,118

Name: PCF8562TT/2,118
Brand: NXP
SKU: 270344
Availability: InStock
Rating: 5 (666 reviews)

Part No	PCF8562TT/2,118
Manufacturer	NXP
Catalog	PMIC - Display Drivers
Description	IC LCD DRIVER 32/128SEG 48-TSSOP
Datasheet	PCF8562TT/2,118 Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $15.6153

Quantity

Unit Price

Ext. Price

$22.6090

$67.827

$18.5510

$111.306

$17.9710

$161.739

12+

$17.3920

$208.704

15+

$16.8120

$252.180

20+

$15.0730

$301.460

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 10,040 pieces

MOQ: 3 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits
Manufacturer	NXP
Packaging	Reel - TR
Status	Active
Display Type	LCD
Configuration	7 Segment + DP, 14 Segment + DP + AP, Dot Matrix
Digits or Characters	8 Characters, 16 Characters
Operating Supply Current	8μA
Supply Voltage - Operating	1.8 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	48-TSSOP
Win Source Part Number	137418-PCF8562TT/2,118
Popularity	Medium
Fake Threat In the Open Market	42 pct.
Supply and Demand Status	Limited

Description

Product Overview: PCF8562TT/2,118

The PCF8562TT/2,118 is a high-quality, versatile LCD driver designed and manufactured by NXP Semiconductors. This integrated circuit (IC) is specifically tailored for driving liquid crystal displays (LCDs), offering a compact, energy-efficient solution for a wide range of applications. Its robust design and advanced technology make it an ideal choice for developers looking to create products with clear, reliable display capabilities.

Key Features

Display Compatibility: Capable of driving LCDs with up to 32 segments and 4 common lines, making it suitable for alphanumeric displays in various consumer electronics.
Interface: Includes an I²C-bus interface which allows for easy integration into most microcontroller-based systems, ensuring a seamless communication with the host controller.
Low Power Consumption: Designed with power efficiency in mind, it operates with a minimal current draw, which is crucial for battery-powered devices.
Multiple Operating Modes: Features normal, economy, and standby modes, allowing for optimal power management based on the application's requirements.
Package: Comes in a compact Thin Shrink Small Outline Package (TSSOP), specifically the TSSOP20 package, which is ideal for space-constrained applications.

Applications

The PCF8562TT/2,118 is versatile enough to be used in a broad array of devices. It is particularly well-suited for:

Portable instruments
Battery-operated devices
Utility meters
Home appliances
Healthcare devices
Automotive dashboards

Technical Specifications

The device operates over a wide temperature range and is designed to interface with 5 V, 3 V, and 2.5 V microcontrollers, offering flexibility in various system designs. The PCF8562TT/2,118 also includes built-in features such as on-chip generation of LCD supply and bias voltages, reducing the need for external components and simplifying the overall design.

Conclusion

With its combination of features, the PCF8562TT/2,118 from NXP Semiconductors stands out as a reliable and efficient solution for driving mid-sized LCDs. Its ease of integration, low power consumption, and flexibility make it an excellent choice for developers and manufacturers aiming to enhance their products with high-quality display functionality.
