The NXP TDA5145T/C3 is a high-performance, integrated circuit designed to drive brushless DC motors with precision and efficiency. This versatile motor driver is suitable for a wide range of applications, including but not limited to, computer peripherals, cooling fans, and electrically driven pumps. Built with state-of-the-art silicon technology, the TDA5145T/C3 offers a compact, reliable solution for controlling three-phase brushless motors.

Key Features

• Integrated Motor Control: The TDA5145T/C3 integrates all the necessary functions for sensorless commutation of a BLDC motor, reducing the need for external components and simplifying the overall design.
• Sensorless Operation: It utilizes back-EMF detection for rotor position sensing, eliminating the need for external Hall-effect sensors and reducing system complexity and cost.
• Speed Control: The device supports a wide range of speed control options, including PWM and analog voltage input, offering flexibility in motor speed regulation.
• Built-in Protection Features: The motor driver includes several protection features such as locked rotor protection, undervoltage lockout, and thermal shutdown to ensure safe operation under various conditions.
• Soft Switching: To minimize EMI and reduce power losses, the TDA5145T/C3 employs soft switching of the motor coils.

Technical Specifications

• Supply Voltage: The device operates over a wide supply voltage range, accommodating various application requirements.
• Output Current: It is capable of delivering continuous output current to drive motors with different power ratings.
• Package: The TDA5145T/C3 is available in a compact SO20 package, making it suitable for space-constrained applications.

Applications

The NXP TDA5145T/C3 is an ideal choice for designers looking to implement a brushless DC motor control solution in their products. Its robust design and advanced features make it well-suited for applications that require reliable and efficient motor operation.

Ordering Information

For ordering, the TDA5145T/C3 is available through NXP's authorized distributors. Detailed product information and support documentation can be found on the NXP website or by contacting their sales and support team directly.
