The TDA7052AT/N2 is a high-quality audio amplifier integrated circuit (IC) designed and manufactured by NXP Semiconductors. This mono bridge-tied load (BTL) amplifier is perfect for portable audio applications due to its low voltage operation and minimal external component requirement. The IC is widely appreciated for its simplicity and efficiency, making it an ideal choice for small projects and consumer electronic products.

Key Features

• Power Output: The TDA7052AT/N2 can deliver 1 Watt of continuous output power to an 8 Ohm load with a 6 V power supply, making it suitable for a range of audio applications.
• Supply Voltage: It operates on a wide supply voltage range from 4.5 V to 18 V, providing flexibility in various power environments.
• No External Components: One of the significant advantages of this IC is that it does not require any external components for operation, such as bootstrap capacitors or snubber networks.
• Volume Control: The amplifier includes an integrated volume control feature, which allows for easy adjustment of the audio output level.
• Low Quiescent Current: The TDA7052AT/N2 has a low quiescent current draw, which helps in conserving battery life in portable devices.
• Mute Mode: The IC also features a mute function that can be activated via a DC voltage level, providing additional control over the audio output.

Applications

The TDA7052AT/N2 is ideal for a wide range of audio applications, including but not limited to:

• Portable audio devices such as radios and toys
• Small personal computers or laptops
• Battery-powered speakers
• Intercom systems

With its compact SOT96-1 package, the TDA7052AT/N2 is easy to integrate into various designs, offering a robust and reliable audio amplification solution. NXP's commitment to quality ensures that the TDA7052AT/N2 delivers consistent performance, making it a preferred choice for designers and hobbyists alike.
