The TJA1048T,118 is a high-speed Controller Area Network (CAN) transceiver designed by NXP Semiconductors. This device provides an interface between a CAN protocol controller and the physical two-wire CAN bus. It is specifically tailored for high-speed automotive networking applications that require data rates up to 1 Mbit/s. The TJA1048T,118 is a part of NXP's leading-edge high-speed CAN transceiver family that ensures reliable communication with excellent electromagnetic compatibility (EMC) performance.

Key Features

• Compatible with the ISO 11898-2:2016 standard.
• Supports CAN FD for up to 5 Mbit/s (in the data phase).
• Low electromagnetic emission (EME) and high electromagnetic immunity (EMI).
• Differential receiver with wide common-mode range for high EMC robustness.
• Transmit Data (TXD) dominant time-out function to prevent bus line lock-up.
• Remote wake-up capability via the CAN bus.
• Thermal protection, as well as short-circuit proof to battery and ground.
• Very low current standby mode with bus wake-up capability.
• Available in an SO8 package, suitable for small form factor applications.

Applications

The TJA1048T,118 is ideal for a wide range of automotive applications where high-speed data transmission and reception are critical. These include:

• Powertrain systems
• Chassis control modules
• Gateway modules
• Body control modules
• Advanced driver-assistance systems (ADAS)
• Infotainment systems

Reliability and Quality

NXP's TJA1048T,118 transceiver is designed with a focus on reliability and quality, ensuring long-term performance in the demanding automotive environment. With features such as thermal protection and bus fault protection, it ensures communication resilience and system safety.

Environmental and Regulatory Compliance

The device is compliant with automotive industry regulations and standards, including AEC-Q100 qualification for automotive quality and reliability. It also adheres to the Restriction of Hazardous Substances (RoHS) directive, making it an environmentally friendly choice for modern automotive designs.
