The NXP UJA1169ATK/F/3Z is a state-of-the-art System Basis Chip (SBC) designed to support the secure, reliable, and efficient functioning of automotive control units. This compact, integrated component is tailored for use in applications that demand high levels of energy efficiency and robustness, such as body control modules, gateway modules, and various sensor interfaces within a vehicle.

Key Features

• High Integration: The UJA1169ATK/F/3Z integrates a CAN transceiver, voltage regulator, and watchdog in a single package, reducing the number of individual components required on a board and aiding in cost and space reduction.
• CAN FD Support: It supports the latest CAN Flexible Data rate (FD) for faster data transmission rates, ensuring compatibility with modern vehicular communication networks.
• Low Power Consumption: The device features a low-power standby mode with bus wake-up capability, making it ideal for applications requiring minimal quiescent current to conserve battery life.
• Enhanced Safety: The inclusion of a windowed watchdog timer helps to ensure that the system operates within specified parameters, enhancing the overall safety and reliability of the control unit.
• Robust Design: Designed to withstand the harsh automotive environment, the UJA1169ATK/F/3Z is compliant with the ISO 11898-2:2016 standard and is AEC-Q100 qualified.

Applications

The versatility of the NXP UJA1169ATK/F/3Z makes it suitable for a variety of automotive applications, such as:

• Body Control Modules
• Gateway Modules
• Powertrain and Engine Control Units
• Chassis Control Modules
• Advanced Driver-Assistance Systems (ADAS)

Technical Specifications

With a wide operating voltage range and the ability to interface directly with microcontrollers, the UJA1169ATK/F/3Z is designed to meet the rigorous demands of automotive electronics. The device is available in a small HVSON14 package, ensuring a compact footprint for space-constrained applications.

By integrating the UJA1169ATK/F/3Z into your automotive control systems, you are choosing a product that delivers high performance, reliability, and the quality assurance of NXP Semiconductors, a leading provider of automotive solutions.
