S82S-7705 Real Image
Same model may have multiple batches, images only for reference.

S82S-7705

Part No S82S-7705
Manufacturer Omron
Catalog Power Supplies Board Mount DCDC Converters
Description POWER SUPPLY SWITCHING 5V 1.5A
Datasheet
S82S-7705 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - External/Internal (Off-Board)
Manufacturer Omron Automation and Safety
Series S82S
Packaging Bulk
Input Voltage MIN 12V
Voltage Input MAX 24V
Number of Outputs 1
Voltage - Output 1 5V
Current - Output (Maximum) 1.5A
Power (Watts) 7.5W
Mounting DIN Rail
Package Module
Dimension 2.56" L x 1.48" W x 2.95" H (65mm x 37.5mm x 75mm)
Approvals CE, CSA, UL, VDE
Win Source Part Number 761903-S82S-7705
Popularity Medium
Supply and Demand Status Sufficient
Family Name S82S-7705
Introduction Date June 01, 2006
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian S82S-7705 CAD Model

Description

The Omron 761903-S82S-7705 is a power supply from Omron.

  • Power Rating: 7.5W
  • Output Voltage: 5V
  • Mounting Style: DIN Rail
  • Input Voltage: 12V - 24V
  • Approvals: CE, CSA, UL, VDE
  • Supply and Demand Status: Sufficient
