The XC5H-4822 is a 48-position, 3-row backplane connector designed for DIN 41612 applications. The connector type is a receptacle female socket, and the device is mounted using through-hole, right-angle technology. The XC5H-4822 has a pitch of 0.100" (2.54mm) and a current rating of 2A. The contact finish is gold with a thickness of 16.0μin (0.41μm). The connector is rated for a temperature range of -55°C to 125°C and is manufactured by Omron Electronics Inc-EMC Div. The XC5H-4822 is supplied in a bulk package with 50 units per standard package.

• Positions: 48
• Rows: 3
• Application: DIN 41612
• Connector Type: Receptacle Female Socket
• Mounting Type: Through-Hole, Right-Angle
• Pitch: 0.100" (2.54mm)
• Current Rating: 2A
• Contact Finish: Gold
• Contact Finish Thickness: 16.0μin (0.41μm)
• Temperature Range: -55°C to 125°C
• Package: Bulk
• Package Quantity: 50
