ON Semiconductor 2N3415 General Purpose Transistor

The ON Semiconductor 2N3415 is a high-performance NPN bipolar junction transistor (BJT) designed for general-purpose amplifier and switching applications. This versatile transistor offers a balanced combination of features that make it suitable for a wide range of electronic circuits.

Key Features:

• Voltage Ratings: The 2N3415 is capable of withstanding collector-emitter voltages up to 50V, making it suitable for various medium-voltage applications.
• Current Handling: With a continuous collector current rating of up to 500mA, this transistor can handle significant current loads for its size.
• Power Dissipation: It has a power dissipation rating of 625mW, which ensures reliable operation under normal ambient temperatures without the need for additional heat sinking.
• Gain Bandwidth Product: The device features a transition frequency of 50MHz, providing a good balance of gain and speed for amplification purposes.
• High DC Current Gain: The transistor has a DC current gain (hFE) range of 40 to 240 at 10mA, which allows for a high level of amplification in various circuit configurations.

Applications:

The 2N3415 transistor is ideal for a multitude of applications, including but not limited to:

• Audio amplifiers and pre-amplifiers
• Signal processing
• Switching and regulation circuits
• Driver stages in hi-fi systems and TVs
• Linear amplification and switching

Quality and Reliability:

ON Semiconductor is known for its commitment to quality, and the 2N3415 transistor is no exception. It is manufactured to stringent quality standards, ensuring consistent performance and reliability for both commercial and industrial applications.

Package and Availability:

The 2N3415 comes in a TO-92 package, which is a widely used and easily mountable package for small-signal transistors. This makes it convenient for prototyping, educational projects, and mass production. The product is available through various distributors and directly from ON Semiconductor, providing flexible procurement options.
