Same model may have multiple batches, images only for reference.
2SA1707T-AN ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

2SA1707T-AN

Part No 2SA1707T-AN
Manufacturer ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS PNP 50V 3A 3-NMP
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Transistor Type PNP
Current - Collector (Ic) (Max) 3 A
Voltage - Collector Emitter Breakdown (Max) 50 V
Vce Saturation (Max) @ Ib, Ic 700mV @ 100mA, 2A
Current - Collector Cutoff (Max) 1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 100mA, 2V
Power - Max 1 W
Frequency - Transition 150MHz
Temperature Range - Operating 150°C (TJ)
Mounting Type Through Hole
Case / Package SC-71
Supplier Device Package 3-NMP
Package Bulk
Supply and Demand Status Limited
Win Source Part Number 1494516-2SA1707T-AN
Ultra Librarian 3D Model Ultra Librarian 2SA1707T-AN CAD Model

Description
