The 2SA1709S-AN is a high-quality PNP transistor manufactured by ON Semiconductor, a company known for its innovative and reliable semiconductor products. This particular component is designed for general-purpose amplifier applications and is especially suitable for use in power management functions due to its efficient performance and energy-saving capabilities.

Key Features

• Transistor Type: PNP - This means the transistor is designed to be controlled by the flow of negative charge carriers (holes).
• Voltage - Collector Emitter Breakdown (Max): -50V - The maximum voltage the collector-emitter junction can withstand when the transistor is off.
• Current - Collector (Ic) (Max): -2A - The maximum current that can flow through the collector of the transistor.
• Power - Max: 900mW - The maximum power this transistor can dissipate without damage.
• DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 500mA, -10V - Indicates the transistor’s ability to amplify the current.
• Operating Temperature: -55°C to +150°C - A wide range that ensures reliability and functionality under various environmental conditions.
• Mounting Type: Surface Mount - The transistor is designed to be mounted directly onto the surface of a printed circuit board (PCB).
• Package / Case: TO-243AA - A small and reliable package that is compatible with automated assembly processes.

Applications

The 2SA1709S-AN transistor is versatile and can be used in various applications. It is ideal for use in:

• Power regulators
• DC-DC converters
• Audio amplifiers
• Signal amplification circuits
• Switching applications

Quality and Reliability

ON Semiconductor's commitment to quality ensures that the 2SA1709S-AN transistor meets the high standards expected by industry professionals. The device is subjected to rigorous testing and quality control measures, guaranteeing performance and reliability for your electronic projects and commercial applications.
