The CM1406-08DE from ON Semiconductor is a cutting-edge EMI (Electromagnetic Interference) filter array designed to provide superior noise suppression in electronic devices. This compact, high-performance component is an ideal solution for space-constrained applications requiring efficient EMI filtering and ESD (Electrostatic Discharge) protection.

Key Features

• Integrated ESD Protection: With built-in ESD protection, the CM1406-08DE safeguards sensitive circuitry against electrostatic discharges, meeting the IEC61000-4-2 Level 4 standard.
• Low Pass Filter Design: The device features a low pass filter architecture, which effectively attenuates unwanted high-frequency noise while allowing desired signals to pass through.
• Multiple Channels: This filter array consists of 8 channels, making it versatile for use in multi-line applications such as data lines or interface ports.
• Compact Size: The CM1406-08DE comes in a micro-miniature package, allowing for efficient use of PCB space without compromising performance.
• High-Speed Signal Integrity: Designed to support high-speed data interfaces, this EMI filter maintains signal integrity while minimizing EMI emissions.

Applications

The CM1406-08DE is highly suitable for a broad range of applications where EMI filtering and ESD protection are critical. Its typical applications include:

• Mobile Phones and PDAs
• Notebook Computers
• Digital Cameras
• MP3 Players
• Portable Gaming Systems
• USB Interfaces and Peripherals

Technical Specifications

The CM1406-08DE boasts impressive technical specifications that ensure reliable performance:

• 8 EMI Filters with Integrated ESD Protection Diodes
• Channel Capacitance: 17pF typical per channel
• ESD Protection: >±15kV air and >±8kV contact discharge
• Low Leakage Current
• Operating Temperature Range: -40°C to +85°C
• Package: 16-lead QFN (3mm x 3mm)

Whether you are designing the latest consumer electronics or looking to improve the EMI performance of existing products, the CM1406-08DE from ON Semiconductor is an excellent choice for your EMI filtering needs.
