Products specifications Report Issue?

Category Integrated Circuits (ICs)>Linear - Amplifiers - Audio
Mfr onsemi
Package Bulk
Type Class AB
Output Type 2-Channel (Stereo)
Max Output Power x Channels @ Load 15W x 2 @ 8Ohm
Voltage - Supply 16.5V ~ 24V
Mounting Type Through Hole
Temperature Range - Operating -25°C ~ 75°C (TA)
Supplier Device Package 12-SIPH
Package / Case 12-SIP Exposed Pad
RoHS Status Not applicable
MSL Level 3 (168 Hours)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.33.0001
Other Names ONSONSLA42152L-E,2156-LA42152L-E
Standard Package 1
Win Source Part Number 995719-LA42152L-E
Ultra Librarian 3D Model Ultra Librarian LA42152L-E CAD Model

Description

The LA42152L-E from ON Semiconductor is a monolithic integrated circuit designed to deliver high-quality audio amplification with minimal components and straightforward implementation. This audio power amplifier is well-suited for a variety of applications, ranging from consumer electronics to automotive audio systems.

Key Features

  • High Output Power: Capable of delivering up to 5.5W (typical) of continuous average power to an 8Ω load with low harmonic distortion, ensuring clear and powerful sound reproduction.
  • Low Voltage Operation: Designed to operate at low voltages, making it ideal for battery-powered devices, with a recommended operating voltage range of 5V to 14.4V.
  • Minimal External Components: Requires very few external components for operation, which simplifies circuit design and reduces overall system cost and complexity.
  • Thermal Shutdown Protection: Equipped with a built-in thermal shutdown mechanism that protects the device from overheating, ensuring reliability and longevity.
  • Pop Noise Suppression: Features pop noise suppression circuitry to minimize noise commonly associated with power cycling, providing a more pleasant user experience.

Applications

The LA42152L-E is versatile and can be used in a wide array of audio applications, including:

  • Portable audio devices
  • Television sound systems
  • Boomboxes and radios
  • Automotive audio systems

Technical Specifications

Parameter Value Output Power 5.5W (typ) @ 8Ω Operating Voltage 5V - 14.4V Total Harmonic Distortion (THD) Low Package SIP-9

With its robust design and high-quality audio output, the LA42152L-E audio power amplifier from ON Semiconductor stands out as a top choice for designers and manufacturers looking for a reliable and efficient solution to integrate into their audio products.
