Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Active
Mode Critical Conduction (CRM)
Current - Startup 250μA
Supply Voltage - Operating 12 V to 28 V
Temperature Range - Operating 0°C to 85°C
Mounting Through Hole
Case / Package 8-PDIP
Win Source Part Number 022694-MC34262PG
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MC34262PG CAD Model

Description

ON Semiconductor MC34262PG Power Factor Controller

The ON Semiconductor MC34262PG is a versatile and highly efficient power factor controller designed for use in switch mode power supplies (SMPS) and other power conversion applications. This integrated circuit is specifically engineered to enhance power factor correction, which is crucial for reducing power consumption and improving the energy efficiency of electronic systems.

Key Features

  • Enhanced Power Factor Correction: The MC34262PG actively shapes the input current wave to align with the AC mains voltage, effectively minimizing reactive power and improving the power factor.
  • Versatile Operating Modes: This device supports both Continuous Conduction Mode (CCM) and Discontinuous Conduction Mode (DCM), providing flexibility for different power supply designs.
  • Integrated Protections: It includes built-in features such as overvoltage protection, undervoltage lockout, and a programmable soft-start function to ensure safe operation under various conditions.
  • Minimal External Components: The MC34262PG is designed to operate with minimal external components, which simplifies the design and reduces the overall bill of materials.

Applications

The MC34262PG is ideal for a wide range of applications where power efficiency is a priority. Common uses include:

  • AC-DC adapters for laptops and other portable devices
  • Power supplies for desktop computers and servers
  • Power supplies for telecommunication equipment
  • Industrial power systems

Technical Specifications

The device operates over a wide supply voltage range and is available in a PDIP-8 package. It has a fixed operating frequency and a typical startup current of 100 µA. The MC34262PG also features a totem pole output, which is capable of directly driving the gate of a power MOSFET.

In summary, the ON Semiconductor MC34262PG power factor controller is an excellent choice for designers looking to improve the energy efficiency and performance of their power supply units. Its integration of advanced features, along with its ability to reduce the number of external components, makes it a cost-effective and reliable solution for a variety of power management applications.
