ON Semiconductor MC7805ACD2TR4G Voltage Regulator

The ON Semiconductor MC7805ACD2TR4G is a robust positive voltage regulator designed to offer a fixed output voltage of 5V with a maximum output current of up to 1A. This integrated circuit is part of the MC78 series and is highly appreciated for its reliability and efficiency in a wide range of applications. It comes in a surface-mount D2PAK package, which is suitable for automated assembly processes and space-constrained applications.

Key Features

• Output Voltage: Precisely regulated 5V output, which is essential for consistent performance of the connected components.
• Output Current: Capable of delivering up to 1A, making it suitable for a variety of low-power applications.
• Thermal Overload Protection: Built-in thermal overload protection ensures the device operates within safe temperature limits, preventing damage from overheating.
• Short Circuit Protection: The regulator includes short circuit protection, which safeguards the device and the circuit from potential damage due to short circuits.
• Low Dropout Voltage: The MC7805ACD2TR4G offers a low dropout voltage, which enhances its efficiency and allows it to operate effectively even with minimal input-to-output voltage differential.
• No External Components Required: This voltage regulator typically does not need external components for stable operation, simplifying design and reducing board space requirements.
• Package: Available in a compact D2PAK surface-mount package, it is ideal for modern, space-sensitive electronic assemblies.

Applications

The MC7805ACD2TR4G is versatile and can be used in various electronic devices and systems. Some of the common applications include:

• Consumer electronics
• Computer peripherals
• Power supplies
• Automotive applications
• Embedded systems

ON Semiconductor's commitment to quality ensures that the MC7805ACD2TR4G voltage regulator is a reliable choice for designers looking to maintain a stable 5V supply in their electronic circuits. Its comprehensive protection features and ease of integration make it a staple component in both commercial and industrial applications.
