ON Semiconductor NCV7342D10R2G Overview

The NCV7342D10R2G is a sophisticated automotive-grade CAN transceiver produced by ON Semiconductor. It is specifically designed to interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. This product is suitable for high-speed automotive networking applications, ensuring reliable communication with excellent protection features.

Key Features

• High-Speed CAN Interface: The NCV7342D10R2G supports the ISO 11898 standard for high-speed CAN applications, enabling data transfer rates of up to 1 Mbps.
• Low Power Mode: An important feature of this transceiver is its low-power mode, which helps reduce power consumption when the network is idle or in standby.
• Thermal Protection: The device includes thermal protection that prevents it from overheating, ensuring long-term reliability and stability in harsh automotive environments.
• Bus Fault Protection: The transceiver is capable of withstanding bus fault conditions of ±36V, providing robustness against electrical disturbances on the CAN bus.
• Wide Operating Temperature Range: It operates across a wide temperature range from -40°C to +125°C, making it suitable for various automotive applications.

Applications

The NCV7342D10R2G is ideal for use in a range of automotive applications, including but not limited to:

• Powertrain Systems
• Chassis Control Modules
• Body Electronics
• Advanced Driver Assistance Systems (ADAS)
• Infotainment Systems

Quality and Reliability

ON Semiconductor has designed the NCV7342D10R2G to meet the stringent requirements of the automotive industry. It is AEC-Q100 qualified, ensuring that it meets the highest quality and reliability standards. Its robust design makes it an excellent choice for automotive engineers looking for a reliable CAN communication solution.

Package and Availability

The device is available in an SOIC-8 package, providing a compact footprint for space-constrained applications. Its lead-free and RoHS-compliant design aligns with current environmental standards, making it a responsible choice for the global automotive market.
