ON Semiconductor NCV7707DQR2G Product Overview

The NCV7707DQR2G from ON Semiconductor is a highly integrated and robust automotive-grade hex half-bridge driver designed to deliver exceptional performance in a wide range of automotive applications. This advanced semiconductor is engineered to manage and drive inductive loads such as relays, solenoids, and other actuators, making it an essential component in vehicle powertrain systems, body electronics, and convenience functions.

Key Features

• High-Voltage Operation: The NCV7707DQR2G is capable of operating at high voltages, providing the necessary power to drive automotive actuators efficiently.
• Multiple Half-Bridge Drivers: It features six half-bridge drivers that can be controlled independently, offering flexibility in connecting and controlling various loads.
• Integrated Protection: The device includes overcurrent protection, undervoltage lockout, and thermal shutdown features to ensure the safety and reliability of the system under harsh automotive conditions.
• SPI Interface: A Serial Peripheral Interface (SPI) allows for digital communication and diagnostics, enabling sophisticated control strategies and feedback on the state of the drivers and connected loads.
• Low RDS(on): The low on-resistance of the output transistors minimizes power dissipation and improves overall efficiency.
• Automotive Grade: Designed to meet the stringent requirements of the automotive industry, it is AEC-Q100 qualified for high reliability.

Applications

The versatility of the NCV7707DQR2G makes it suitable for a variety of applications within the automotive sector, including:

• Engine and powertrain systems
• Automotive lighting control
• Body control modules
• Window lift and sunroof control
• Active grille shutter control

Package and Quality

The NCV7707DQR2G is offered in a compact 48-pin QFN package, which is optimized for space-constrained applications. The package is designed with a lead-free finish and is RoHS compliant, ensuring it meets current environmental standards. Its robust construction ensures it can withstand the rigorous conditions of automotive environments.

With its combination of high performance, integrated protection features, and flexible control options, the NCV7707DQR2G from ON Semiconductor is an excellent choice for designers looking to enhance the efficiency and reliability of their automotive applications.
