ON Semiconductor NGTB15N120FL2WG IGBT - High-Efficiency Power Solution

The NGTB15N120FL2WG from ON Semiconductor represents a cutting-edge insulated gate bipolar transistor (IGBT) designed to deliver high-efficiency and fast-switching performance in a variety of power applications. This IGBT is engineered to meet the demands of modern electronic systems, providing a perfect blend of low conduction losses and minimal switching losses.

Key Features

• High Current Rating: With a continuous collector current of 15A at 25°C, this IGBT can handle significant power levels, making it suitable for high-power applications.
• High Voltage Capability: The device is rated for a collector-emitter voltage of up to 1200V, providing a wide safety margin for applications subject to high voltage transients.
• Low Saturation Voltage: The NGTB15N120FL2WG offers a low V<sub>CE(sat) of typically 2.3V at I<sub>C = 15A, reducing on-state power dissipation and improving efficiency.
• Fast Switching Speed: Its fast-switching capability enhances performance in high-frequency power switching applications, contributing to overall system efficiency.
• Co-Packaged Free Wheeling Diode: Comes with an integrated soft recovery diode which is optimized for minimal reverse recovery time and charge, reducing losses during switching events.

Applications

The NGTB15N120FL2WG IGBT is versatile and can be used in a range of applications, including:

• Uninterruptible Power Supplies (UPS)
• Power Inverter Systems
• Induction Heating
• Motor Drives
• High-Frequency Converters

Package and Reliability

This IGBT is housed in a TO-247 package, which is known for its high power dissipation and excellent thermal characteristics. The robust design ensures reliable performance even under harsh conditions, making it a dependable choice for critical power applications. ON Semiconductor's commitment to quality ensures that the NGTB15N120FL2WG IGBT provides long-term reliability and performance consistency.

With its superior efficiency, power handling, and reliability, the NGTB15N120FL2WG from ON Semiconductor is an ideal choice for designers looking to optimize their power systems for both performance and energy savings.
