NTMJS1D5N04CLTWG ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

NTMJS1D5N04CLTWG

Part No NTMJS1D5N04CLTWG
Manufacturer ON Semiconductor
Catalog Transistors – FETs, MOSFETs – Single
Description MOSFET N-CH 40V 38A/200A 8LFPAK
Datasheet
NTMJS1D5N04CLTWG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 40 V
Current - Continuous Drain (Id) @ 25°C 38A (Ta), 200A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 1.4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id 2V @ 130µA
Gate Charge (Qg) (Max) @ Vgs 70 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 4300 pF @ 20 V
Power Dissipation (Max) 3.8W (Ta), 110W (Tc)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 8-LFPAK
Case / Package SOT-1205, 8-LFPAK56
Package Tape & Reel
Supply and Demand Status Limited
Win Source Part Number 1508892-NTMJS1D5N04CLTWG
Ultra Librarian 3D Model Ultra Librarian NTMJS1D5N04CLTWG CAD Model

Description

N
