The NVDSH20120C is a state-of-the-art N-Channel MOSFET brought to you by ON Semiconductor, a brand synonymous with innovation and quality in the semiconductor industry. This MOSFET is designed to meet the demands of a wide range of high-efficiency applications, including power management, conversion, and more.

Key Features

• Low R<sub>DS(on): The device boasts an ultra-low on-resistance, which translates to reduced conduction losses and improved overall efficiency in applications.
• High Current Capacity: With a continuous drain current of 120 A, the NVDSH20120C is capable of handling high current loads, making it suitable for demanding power applications.
• High Voltage Rating: The MOSFET has a drain-to-source voltage (V<sub>DSS) of 200 V, providing a good safety margin for applications with high voltage requirements.
• PowerPAK® SO-8 Package: The compact and thermally efficient PowerPAK® SO-8 package allows for simplified PCB design and enhanced thermal performance, enabling the device to operate at lower temperatures.

Applications

The NVDSH20120C is versatile and can be used in a variety of applications, including:

• DC/DC Converters
• Power Supply Modules
• Motor Drives
• Automotive Applications
• Switch Mode Power Supplies (SMPS)

Quality and Reliability

ON Semiconductor is committed to delivering high-quality products. The NVDSH20120C MOSFET is no exception, undergoing rigorous testing and quality control measures to ensure reliability and performance in the field. It is designed to meet the requirements of a wide range of industrial and automotive-grade applications, providing a reliable solution for engineers and designers.

Environmental Compliance

The NVDSH20120C is compliant with RoHS and Halogen-Free standards, reflecting ON Semiconductor's dedication to environmental sustainability. This commitment ensures that the MOSFET not only meets current environmental regulations but also contributes to a greener future for electronics.
