Products specifications

Categories Circuit Protection
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 2
STAND-OFF Voltage (Vwm) 5.5V (Max)
Applications Automotive
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package SOT-143-4
Win Source Part Number 045552-PACDN004SR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PACDN004SR CAD Model

Description

The PACDN004SR from ON Semiconductor is a state-of-the-art ESD (Electrostatic Discharge) protection diode designed to safeguard sensitive electronic components from electrostatic shocks. This ESD protection device is a crucial component for modern electronic products, offering robust defense against the transient voltage spikes that can occur during everyday usage, such as during device plugging and unplugging.

Key Features

  • Low Clamping Voltage: The PACDN004SR provides a low clamping voltage, which is essential for protecting sensitive circuits from voltage transients without compromising their performance.
  • Fast Response Time: With an extremely fast response time to ESD strikes, this protection diode ensures that your electronics are shielded promptly from sudden electrical surges.
  • Low Leakage Current: The device exhibits a low leakage current that helps maintain energy efficiency in your electronic systems, ensuring minimal power wastage when the diode is in a standby state.
  • Multiple Channel Protection: This diode is capable of protecting multiple lines, offering a compact and efficient solution for guarding several interfaces at once.
  • Small Package Size: The PACDN004SR comes in a small package, making it suitable for space-constrained applications without sacrificing performance.

Applications

The PACDN004SR is ideal for a wide range of applications where ESD protection is critical. It is commonly used in:

  • Portable Electronics
  • Computer Peripherals
  • Communication Systems
  • Consumer Electronics
  • Networking Devices

Technical Specifications

The PACDN004SR features impressive technical specifications that include:

  • Working Voltage: 5V
  • ESD Withstand Voltage: >25kV (air), >15kV (contact)
  • IEC Compatibility: IEC 61000-4-2 standard
  • Package: SOT-23

In conclusion, the PACDN004SR from ON Semiconductor is an excellent choice for designers looking to integrate ESD protection into their electronic designs. Its combination of low clamping voltage, fast response time, and multi-channel protection, all within a small footprint, makes it a versatile and reliable component for protecting sensitive electronics.
