ON Semiconductor SBRS8140T3G Schottky Barrier Rectifier

The ON Semiconductor SBRS8140T3G is a high-performance Schottky barrier rectifier designed to meet the stringent requirements of today's electronic devices. This rectifier is a perfect choice for applications requiring efficient power management and high reliability. With its low forward voltage drop and fast switching capabilities, it ensures minimal power loss and improved system efficiency, making it ideal for use in a wide range of products.

Key Features

• High Current Capability: The SBRS8140T3G is capable of conducting up to 1 A of continuous forward current, making it suitable for high-current applications.
• Low Forward Voltage Drop: With a forward voltage drop as low as 0.71 V, this device ensures low power dissipation, contributing to overall energy savings in the application circuit.
• Fast Switching Speed: The fast switching action of the SBRS8140T3G minimizes transition losses and enhances performance in high-frequency circuits.
• High Surge Capacity: It can withstand surge currents, providing robust performance under transient conditions.
• Low Power Loss: High efficiency is achieved due to the reduced power loss during operation.
• Guard Ring Die Construction: The guard ring design provides enhanced reliability and stability by protecting against voltage spikes and transients.

Applications

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• DC-DC converters
• Automotive applications

Package and Environmental Compliance

The SBRS8140T3G comes in a compact SMB package, which not only saves space on the PCB but also ensures a robust and durable connection. ON Semiconductor is committed to environmental sustainability, and this product complies with RoHS (Restriction of Hazardous Substances) directives, ensuring that it is free from harmful substances and suitable for use in green products.

Whether you are designing power supply modules, automotive electronics, or portable devices, the ON Semiconductor SBRS8140T3G Schottky barrier rectifier is an excellent choice for ensuring efficient and reliable operation.
