AXK6A2337YG Real Image
Same model may have multiple batches, images only for reference.

AXK6A2337YG

Part No AXK6A2337YG
Manufacturer Panasonic
Catalog Circular Connectors - Housings
Description CONN HDR 120POS SMD GOLD  /  120 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Mfr Panasonic Electric Works
Series P5K
Package Tape & Reel (TR)
Connector Type Header, Outer Shroud Contacts
Number of Positions 120
Pitch 0.020" (0.50mm)
Number of Rows 2
Mounting SMD (SMT)
Features Board Guide
Contact Finish Gold
Mated Stacking Heights 3mm
Height Above Board 0.094" (2.40mm)
Base Product Number AXK6A2337
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Standard Package 1,500
Win Source Part Number 1136508-AXK6A2337YG
Ultra Librarian 3D Model Ultra Librarian AXK6A2337YG CAD Model

Description

This rectangular connector array, part number 1136508-AXK6A2337YG, is a member of the P5K series and is designed for use in board to board mezzanine applications.

  • Part Number: 1136508-AXK6A2337YG
  • Series: P5K
  • Application: Board to Board Mezzanine
  • Positions: 120
  • Pitch: 0.020 inches (0.50mm)
  • Packaging: Tape and Reel (TR)
  • Standard Package: 1,500
  • Mated Stacking Heights: 3mm
  • Height Above Board: 0.094 inches (2.40mm)
  • Mount: SMD (SMT)
  • Manufacturer: Panasonic Electric Works
  • MSL Level: 1 (unlimited)
  • HTSUS: 8536.69.4040
