Same model may have multiple batches, images only for reference.
ECH-U01223JX5 Real Image
Same model may have multiple batches, images only for reference.

ECH-U01223JX5

Part No ECH-U01223JX5
Manufacturer Panasonic
Catalog Film Capacitors
Description CAP FILM 0.022UF 5% 10VDC 0805
Datasheet
ECH-U01223JX5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Capacitors
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Obsolete(EOL)
Capacitance 0.022μF
Tolerance ±5%
Voltage Rating - DC 10V
Dielectric Material Polyphenylene Sulfide (PPS), Metallized - Stacked
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max) 0.043" (1.10mm)
Termination Solder Pads
Applications General Purpose
Win Source Part Number 108780-ECH-U01223JX5
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECH-U01223JX5 CAD Model

Description

Features and Benefits of ECH-U01223JX5

  • Low noise generation
  • Superior thermal management capabilities
  • Long service life with minimal maintenance

Applications

  • Consumer audiovisual equipment
  • Medical instrumentation
  • Data processing and storage applications

Designed for high-performance environments, the ECH-U01223JX5 offers low noise and excellent thermal management, ensuring longevity and consistent operation in precision-demanding sectors.
