The ECHU1H561GX5 is a film capacitor manufactured by Panasonic. As part of the EC Series, it is known for its high reliability and stable performance in various electronic circuits. It is designed for applications that demand consistent capacitance and minimal losses.

Applications:

• Power supplies
• Inverters
• Audio equipment
• Lighting ballasts
• General-purpose electronic circuits

Features:

• Capacitance: 560pF
• Voltage Rating: 50V DC
• Tolerance: ±2%
• Dielectric Material: PPS (Polyphenylene Sulfide) Film
• Operating Temperature Range: -40°C to +105°C
• RoHS Compliant: Yes
• Lead Spacing: 5mm
• Flame Retardant Epoxy Resin Coating: Enhances moisture resistance and provides electrical insulation.
• Self-Healing Properties: Recovers from minor over-voltage events, improving reliability.

Benefits:

• High Stability: The PPS film dielectric offers excellent capacitance stability across a broad temperature range.
• Low Losses: Ensures efficient performance in high-frequency circuits.
• Long Life: Built for long-term reliability in demanding conditions.
• Compact Size: Facilitates dense circuit board designs.
• Safety: The flame retardant coating provides enhanced safety.

Additional Details:

The ECHU1H561GX5 is constructed using a metallized PPS film, resulting in a stable capacitance value and a low dissipation factor. Its compact form factor makes it suitable for applications where board space is limited. The capacitor's robust electrical characteristics and high reliability make it a preferred choice for a wide array of electronic devices.

This capacitor is commonly used in filtering, coupling, decoupling, and timing circuits. The 2% tolerance ensures accurate performance in critical applications.
