ECQB1H222JF3

Part No ECQB1H222JF3
Manufacturer Panasonic
Catalog Film Capacitors
Description Cap Film 2200PF 5% 50VDC Radial
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Capacitance 2.2 nF
Case / Package Radial
Depth 3 mm
Dielectric PET
Dielectric Material Polyester
Height - Seated (Max) 7.0104 mm
Lead Diameter 500 µm
Lead Free Lead Free
Lead Pitch 5.0038 mm
Length 7 mm
Max Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
RoHS Compliant
Termination PC Pins
Tolerance 5 %
Voltage Rating (DC) 50 V
Width 2.9972 mm
Win Source Part Number 1107157-ECQB1H222JF3
Categories Film Capacitors
Manufacturer Panasonic
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ECQB1H222JF3 CAD Model

Description

The Panasonic ECQB1H222JF3 is a radial film capacitor with a capacitance of 2.2 nF and a tolerance of 5%.

  • Voltage Rating: 50 V
  • Lead-Free: Yes
  • Length: 7 mm
  • Width: 2.9972 mm
  • Height (seated): 7.0104 mm
  • Mounting: Through-hole
  • Lead Pitch: 5.0038 mm
  • Operating Temperature Range: -40 °C to 105 °C
  • RoHS Compliant: Yes
