Same model may have multiple batches, images only for reference.
JC2AJ-DC12V Real Image
Same model may have multiple batches, images only for reference.

JC2AJ-DC12V

Part No JC2AJ-DC12V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPST 10A 12V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Obsolete(EOL)
Relay Type General Purpose
Coil Type Non Latching
Coil Current 83.3mA
Coil Voltage 12VDC
Contact Form DPST (2 Form A)
Contact Rating (Current) 10A
Switching Voltage 250VAC - Max
Turn On Voltage (Max) 9.6 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 15ms
Release Time 2ms
Mounting Through Hole
Termination Style PC Pin
Coil Power 1 W
Coil Resistance 144 Ohms
Temperature Range - Operating -50°C to 60°C
Win Source Part Number 205731-JC2AJ-DC12V
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian JC2AJ-DC12V CAD Model

Description

The Panasonic Electric Works JC2AJ-DC12V Relay is a high-quality component designed for use in a variety of applications.

  • Contact Form: DPST (2 Form A)
  • Coil Voltage: 12VDC
  • Contact Rating (Current): 10A
  • Switching Voltage: 250VAC - Max
  • Turn On Voltage (max): 9.6 VDC
  • Turn Off Voltage (min): 1.2 VDC
  • Coil Power: 1 W
  • Coil Resistance: 144 Ohms
  • Packaging: Bulk
  • Mounting: Through-Hole
  • Use: General-Purpose
  • Release Time: 2ms
  • Operate Time: 15ms
  • RoHS Compliant: Yes
  • Temperature Range: -50°C to 60°C
