Win Source Part Number 1085311-PJS6407
Categories OEM Parts(O-R)
Manufacturer Panjit
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian PJS6407 CAD Model

Description

The PJS6407 is a P-Channel enhancement mode MOSFET from Panjit, designed for efficient power management and load switching applications. Its low on-resistance and compact size make it suitable for portable devices and space-constrained applications.

Applications:

  • Load Switching: Used to efficiently control power to various components within electronic systems.
  • Power Management Circuits: Enables efficient power distribution and regulation in battery-powered devices.
  • DC-DC Converters: Can be used in DC-DC converters requiring a low RDS(on) MOSFET.
  • Portable Electronics: Ideal for use in smartphones, tablets, and other mobile devices.

Features:

  • P-Channel Enhancement Mode MOSFET: Simplifies gate drive requirements.
  • Low On-Resistance (RDS(on)): Minimizes power losses and improves overall efficiency.
  • Small Footprint Package: Allows for compact designs and efficient use of board space.
  • Fast Switching Speed: Enhances the switching performance of the circuit.

Benefits:

  • Increased Efficiency: Low on-resistance reduces power dissipation, extending battery life in portable applications.
  • Compact Design: Small package size enables integration into space-limited designs.
  • Simplified Circuit Design: P-channel configuration simplifies gate drive requirements.
  • Reliable Operation: Designed for stable and consistent performance in demanding operating conditions.

Specifications:

The PJS6407 typically features a drain-source voltage (VDS) rating of -20V, continuous drain current (ID) of -5.2A, and an on-resistance (RDS(on)) of 35 mΩ at VGS = -4.5V. The gate-source voltage (VGS) is rated at ±12V. It's commonly available in a SOT-23 package.
