PDA012A-350C-H-R

Part No PDA012A-350C-H-R
Manufacturer Phihong USA
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRIVER CC AC/DC 20-34.4V
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Programmable Not Verified
Type Constant Current
Topology AC DC Converter
Number of Outputs 1
Voltage - Input (Min) 185VAC
Voltage - Input (Max) 304VAC
Voltage - Output 20 ~ 34.4V
Current - Output (Max) 350mA
Power (Watts) 12 W
Voltage - Isolation 3 kV
Features OCP, OTP, OVP, SCP
Ratings IP20
Temperature Range - Operating -40°C ~ 50°C
Efficiency 75%
Termination Style Connector
Size / Dimension 2.81" L x 1.33" W x 1.81" H (71.5mm x 33.8mm x 46.0mm)
Approval Agency CE, cULus
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1569652-PDA012A-350C-H-R
Ultra Librarian 3D Model Ultra Librarian PDA012A-350C-H-R CAD Model
