T1094NLT Real Image T1094NLT real image
Same model may have multiple batches, images only for reference.
T1094NLT Real Image T1094NLT real image
T1094NLT Real Image T1094NLT real image
Same model may have multiple batches, images only for reference.

T1094NLT

Part No T1094NLT
Manufacturer Pulse
Catalog Pulse Transformers
Description T1/CEPT/ISDN-PRI TRANSFORMERS | XFRMR 1CT:1CT/1CT:2CT 1.2/1.2MH
Datasheet
T1094NLT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Pulse Electronics Network
Packaging Reel
Transformer Type T1/E1 (Dual)
Inductance 1.2mH, 1.2mH
Mounting Style SMD
Parts Dimension 0.505" L x 0.280" W (12.83mm x 7.11mm)
Height - Seated (Maximum) 0.245" (6.22mm)
Temperature Range - Operating -40°C ~ 85°C
Weight 0.032 oz (0.912g)
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1263370-T1094NLT
Manufacturer Homepage www.pulseeng.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian T1094NLT CAD Model

Description

The 1263370-T1094NLT transformer from Pulse Electronics Network is a T1/E1 (Dual) transformer that is designed to provide reliable performance.

  • Type: T1/E1 (Dual)
  • Inductance: 1.2mH
  • Supply and Demand Status: Limited
  • Temperature Range: -40°C to 85°C
