The RDA5807HP is a single-chip broadcast FM stereo tuner. It integrates a complete receiver function, from RF input to audio output, making it ideal for portable devices. It is a highly integrated solution utilizing CMOS process technology and supports FM bands worldwide. Compared to other solutions, it typically offers competitive performance and a reduced bill of materials.

Applications

• Mobile phones
• MP3/MP4 players
• Portable FM radios
• Personal Digital Assistants (PDAs)
• FM radio modules

Features

• Worldwide FM band support (76-108MHz)
• Low power consumption
• High sensitivity
• Digital low-IF architecture
• FM stereo receiver functionality
• Automatic Frequency Control (AFC)
• Automatic Gain Control (AGC)
• Digital noise suppression
• Bass boost
• Programmable de-emphasis (50/75 μs)
• I2C control interface
• Few external components required

Benefits

• Enables FM radio capabilities in a variety of portable devices.
• Extends battery life due to low power consumption.
• Provides clear and stable FM reception in various environments.
• Simplifies design and reduces the overall cost of the product.
• Easy integration with other system components through the I2C interface.

Additional Details

The RDA5807HP's digital low-IF architecture contributes to its high performance and low power consumption. It supports both 50 and 75 μs de-emphasis, making it adaptable to different FM broadcast standards globally. The integration of features like AFC and AGC ensures stable and consistent audio quality. The device is typically controlled via an I2C interface, providing flexibility in system design.
