RACD03-500

Part No RACD03-500
Manufacturer Recom Power
Catalog External/Internal (Off - Board) LED Drivers
Description LED DRVR CC/CV AC/DC 3-9.5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Not For New Designs
Programmable Not Verified
Type Constant Current, Voltage
Topology AC DC Converter
Number of Outputs 1
Voltage - Input (Min) 90VAC
Voltage - Input (Max) 264VAC
Voltage - Output 3 ~ 9.5V
Current - Output (Max) 500mA
Power (Watts) 3 W
Voltage - Isolation 3 kV
Features OCP, OTP, OVP, SCP
Ratings IP66
Temperature Range - Operating -20°C ~ 50°C
Efficiency 71%
Termination Style Wire Leads
Size / Dimension 2.05" L x 1.17" W x 0.91" H (52.1mm x 29.6mm x 23.1mm)
Approval Agency CE, cURus, EAC, ENEC
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1542914-RACD03-500
Ultra Librarian 3D Model Ultra Librarian RACD03-500 CAD Model
