ICL7660CBAZ Real Image ICL7660CBAZ Real Image1 ICL7660CBAZ Real Image2
ICL7660CBAZ Real Image ICL7660CBAZ Real Image1 ICL7660CBAZ Real Image2
Same model may have multiple batches, images only for reference.

ICL7660CBAZ

Part No ICL7660CBAZ
Manufacturer Renesas Electronics America
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description Charge Pump INV/STPUP/STPDN -1.5V to -10V/18.6V 45mA 8-Pin SOIC N Tube / CMOS Voltage Converters | IC REG CHARG PUMP INV 45MA 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Renesas Electronics America Inc.
Packaging Tube
Function Ratiometric
Output Configuration Positive or Negative
Topology Charge Pump
Output Type Fixed
Voltage - Input (Minimum) 1.5V
Voltage - Input (Maximum) 10V
Min/Fixed Output Voltage -Vin, 2Vin
Output Current 45mA
Switching Frequency 10kHz
Temperature Range - Operating 0°C ~ 70°C
Mounting Style SMD
Manufacturer Package 8-SOIC
Supplier Device Package 8-SOIC
Family Part Number ICL7660
Manufacturer Pack Quantity 98
MSL Level 1 (Unlimited)
Win Source Part Number 1183387-ICL7660CBAZ
Manufacturer Homepage www.intersil.com/cda/home
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management
Family Name ICL7660
Introduction Date March 29, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian ICL7660CBAZ CAD Model

Description

The Renesas Electronics America Inc. 1183387-ICL7660CBAZ is a fixed output type electronic component that functions as a ratiometric.

  • Topology: Charge pump
  • Output Configuration: Positive or negative
  • Maximum Output Voltage: -
  • Temperature Range: 0°C ~ 70°C
  • Commonly Used In: Power management applications
