Same model may have multiple batches, images only for reference.
PS9031-Y-V-F3-AX Real Image
Same model may have multiple batches, images only for reference.

PS9031-Y-V-F3-AX

Part No PS9031-Y-V-F3-AX
Manufacturer Renesas Electronics America
Catalog Isolators - Gate Drivers
Description HI-SPEED OPTOCPLR LSO5 / 2.5A Gate Driver Optical Coupling 5000Vrms 1 Channel 5-SOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Isolators - Gate Drivers
Manufacturer Renesas Electronics America Inc
Packaging Reel - TR
Technology Optical Coupling
Number of Channels 1
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Min) 50kV/µs
Propagation Delay tpLH / tpHL (Max) 175ns, 175ns
Pulse Width Distortion (Max) 75ns
Rise / Fall Time (Typ) 40ns, 40ns
Current - Output High, Low 2A, 2A
Current - Peak Output 2.5A
Voltage - Forward (Vf) (Typ) 1.56V
Current - DC Forward (If) (Max) 25 mA
Voltage - Output Supply 15V ~ 30V
Temperature Range - Operating -40°C ~ 125°C
Mounting Surface Mount
Case / Package 6-SOIC (0.295", 7.50mm Width), 5 Leads
Supplier Device Package 5-SOP
Approval Agency CSA, UL, VDE
Base Product Number PS9031
RoHS Status ROHS3 Compliant
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Other Part Number 559-PS9031-Y-V-F3-AXCT,559-PS9031-Y-V-F3-AXTR,PS9031-Y-V-F3-AX-ND,559-PS9031-Y-V-F3-AXDKR
Standard Package 3,000
Win Source Part Number 1331870-PS9031-Y-V-F3-AX
Ultra Librarian 3D Model Ultra Librarian PS9031-Y-V-F3-AX CAD Model

Description

The Renesas Electronics America Inc PS9031-Y-V-F3-AX is an optical coupling isolator manufactured by Renesas Electronics America Inc.

  • Category: Isolators-gate drivers
  • Standard Package: 3,000
  • Mounting: Surface mount
  • Voltage Isolation: 5000Vrms
  • Common Mode Transient Immunity: 50kV/μs
  • Propagation Delay tpLH/tpHL: 175ns
  • Current Output High: 2A
  • Current Output Low: 2A
  • Current Peak Output: 2.5A
  • Pulse Width Distortion: 75ns
  • Temperature Range: -40°C to 125°C
  • ROHS3 Compliant: Yes
  • Approvals: CSA, UL, VDE
