Manufacturer RF Micro Devices
Win Source Part Number 293507-RF3133
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF3133 CAD Model

Description

The RF3133 is a power amplifier module designed for GSM/EDGE applications in the 880-915 MHz band, manufactured by RF Micro Devices (now Qorvo). It's engineered to provide high power efficiency and gain, making it suitable for use in cellular handsets and wireless data devices. The module integrates multiple functions to minimize external components and simplify the design process.

Applications:

  • GSM 850/900 cellular handsets
  • EDGE wireless data devices
  • Wireless communication equipment

Features:

  • High power-added efficiency (PAE)
  • High gain
  • Integrated power control
  • Low voltage operation
  • Compact surface mount package

Benefits:

  • Extends battery life in portable devices due to high PAE.
  • Simplifies design and reduces board space due to integration.
  • Provides strong signal amplification for reliable communication.
  • Compatible with low voltage power supplies.
  • Facilitates easy assembly and integration into compact devices.

Additional Details:

The RF3133 operates at a supply voltage between 3.0V and 4.8V. It uses GaAs HBT technology to achieve high efficiency and linearity. The integrated power control circuitry enables precise adjustment of output power to optimize performance. This module is designed to meet the rigorous requirements of GSM/EDGE standards, ensuring reliable performance in demanding wireless environments. The small footprint package makes it ideal for use in compact mobile devices. It provides excellent harmonic performance.
