Same model may have multiple batches, images only for reference.

FRG250-16F

Name: FRG250-16F
Brand: RFE/Fuzetec
SKU: 592948
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	FRG250-16F
Manufacturer	RFE/Fuzetec
Catalog	PTC Resettable Fuses
Description	RESETTABLE FUSE - PPTC RADIAL LE
Datasheet	FRG250-16F Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - PTC Resettable Fuses
Mfr	RFE/Fuzetec
Series	FRG
Package	Bulk
Product Status	Active
Voltage - Max	16V
Current - Hold (Ih) (Max)	2.5 A
Current - Trip (It)	4.7 A
Current - Max	100 A
Time to Trip	5 s
Resistance - Initial (Ri) (Min)	22 mOhms
Resistance - Post Trip (R1) (Max)	53 mOhms
Temperature Range - Operating	-40°C ~ 85°C
Mounting Type	Through Hole
Package / Case	Radial, Disc
Size / Dimension	0.350" L x 0.118" W (8.90mm x 3.00mm)
Height - Seated (Max)	0.504" (12.80mm)
Lead Spacing	0.201" (5.10mm)
Approval Agency	cUL, TUV, UL
Standard Package	1 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8533.40.8070
Win Source Part Number	592948-FRG250-16F
Ultra Librarian 3D Model	Ultra Librarian FRG250-16F CAD Model

Alternative Products

Description

The FRG250-16F is a PTC resettable fuse from the FRG series, designed for circuit protection.

Series: FRG
Package: Bulk
Size: 0.350" L x 0.118" W (8.90mm x 3.00mm)
Seated Height: 0.504" (12.80mm)
Maximum Voltage: 16V
Maximum Current: 100A
Hold Current (Ih): 2.5A
Trip Current (It): 4.7A
Time to Trip: 5 seconds
Mounting Type: Through-hole
Package: Radial, disc
Operating Temperature Range: -40°C to 85°C
Initial Resistance (Ri): 22 mOhms
Post-Trip Resistance (R1): 53 mOhms
Status: Active
Approvals: cUL, TUV, and UL
REACH Regulation: Unaffected
Manufacturer: RFE/Fuzetec
