Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Purpose Driver - Fully Integrated, Control and Power Stage
Technology DMOS
Applications Battery Powered
Output Current 500mA
Supply Voltage - Operating 2.5 V to 5.5 V
Voltage - Load 4 V to 13.5 V
Temperature Range - Operating -25°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 24-HTSSOP-B
Win Source Part Number 011442-BD6380EFV-E2
Family Name BD6380
Introduction Date March 21, 2007
ECCN EAR99
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BD6380EFV-E2 CAD Model

Description

Overview

The BD6380EFV-E2 is an advanced stepper motor driver IC optimized for high-speed, high-torque applications. It offers precision control with enhanced stability, making it ideal for a variety of electromechanical projects.

Applications

  • CNC Machines
  • Medical Equipment
  • Automated Teller Machines (ATMs)
  • Surveillance Systems

Features and Benefits

  • Precision Control: Allows for meticulous control over motor positions.
  • High Torque: Suitable for applications requiring significant power output.
  • Thermal Management: Built-in thermal protection prevents damage from overheating.
  • Easy Integration: Designed for quick and efficient setup in various systems.

Additional Details

Engineered for reliability, the BD6380EFV-E2 features advanced noise reduction and interference prevention mechanisms, making it suitable for sensitive environments and high-demand applications.
